Static Var Generator(SVG)





 Product overview:

Static Var Generator, abbreviated as SVG. Also known as dynamic reactive power compensation generator, or static synchronous compensator. A self-commutating power semiconductor bridge converter is used to compensate dynamic reactive power.









NY50S44FC NY75S44FC
NY100S44FC



SVG Working Principle:


Norya series Static Var Generator through the external current transformer, monitoring load current in real time, and through the internal DSP calculation to analyze the reactive content  of load current. Then according to the set value to control the PWM signal, which sends control signal to the internal IGBT so that the inverter produces reactive power compensation current to meet the requirements to achieve the purpose of dynamic reactive power compensation.




Product model naming rules:



Technical Parameter

Item  Item description
Electrical specifications  Input line voltage  380V±15%
Number of phases  Three-phase four-wire;Three-phase three-wire
Capacity  20~100kVar(Depending on the model)
Frequency  50/60±5Hz(User set)
Response time  <15ms
Power factor correction  -1 to 1 adjustable
Multiple operation  Up to 8 modules in parallel
Efficiency Up to 97.5%
CT ratio range  150:5~6000:5
Dry contacts  EPO/DI/DO
Communication interface  Communication  RS232/RS485/Ethernet/GPRS
Usage areas  Indoor, without direct sunlight, no dust, no corrosive and flammable gases, no oil mist, no water vapor, no drip or salt etc..
Environmental specifications  Working elevation  Below 1000 meters. Derate when higher than 1000 meters, derate 1% for every 100 meters increase.
Storage temperature  -20°C~+70°C
Working temperature  -10°C~+40°C
Humidity  Less than 95%RH, without water droplets condensation.
Vibration  Less than 5.9 m/s2(0.6g)
Structure  Degree of protection  IP20
Colour  7035 gray /7021 black (Customizable)
Net weight  20KG~50KG(Depending on the model)
Cooling method  Intelligent air cooling


SVG Product Features





Traditional reactive power compensation is prone to over or under compensation.


In SVGC, SVC performs stage-level switching compensation.


SVG module performs blind spot coverage to realize stepless switching.



Users can flexibly configure the SVG module and SVC according to the requirements, and realize the application advantages in different aspects
Performance advantage: SVG enables SVGC compensation range from -1~1 to compensate for blind spot coverage simultaneously
Optimize the investment recovery: According to different compensation needs to customize different product mix, to achieve the best investment recovery
Expand the coverage of the application industry: Compared with the pure SVC, it can be applied to the occasions that the load reactive power rapidly changes so that the application industry is expanded

The benefits of managing power quality:

Governance of reactive power

To reduce the cost of enterprise electricity;

To improve the power factor and avoid fines from the power sector;

To reduce line loss and occupancy of the upper level transformer capacity;

To reduce the loss of active power and voltage drop, release the transformer and generator capacity.
